The 2026 Harley-Davidson® Street Glide® 3 Limited is a three-wheel touring motorcycle designed to combine long-distance capability, substantial engine performance, integrated rider technology, and extensive storage capacity. Built around the Milwaukee-Eight® VVT 117 powertrain, this model incorporates a touring-focused chassis, electronic rider assistance systems, advanced infotainment features, and a dedicated reverse function. Its engineering package emphasizes stable operation, rider convenience, and comprehensive functionality for extended travel. The following overview examines the motorcycle’s engine, drivetrain, chassis design, suspension, braking systems, technology features, comfort-oriented equipment, and safety enhancements.
Engine and Performance
The 2026 Harley-Davidson® Street Glide® 3 Limited is powered by the Milwaukee-Eight® VVT 117 engine, a large-displacement V-twin designed to deliver strong output across a broad operating range. This engine features a displacement of 117 cubic inches, or 1,923 cc, along with a bore measuring 4.075 inches and a stroke measuring 4.5 inches. The compression ratio is rated at 10.3:1, contributing to the engine's performance characteristics and combustion efficiency. According to the listed specifications, the engine produces 129 ft-lb of torque at 3,250 rpm and delivers 105 horsepower, or 78 kW, at 4,600 rpm. These output figures provide the foundation for the motorcycle’s touring-oriented performance profile.
Engine Architecture
The Milwaukee-Eight® VVT 117 utilizes pushrod-operated overhead valves with hydraulic self-adjusting lifters. The engine incorporates four valves per cylinder, supporting airflow management within the combustion process. Hydraulic lifters reduce the need for routine valve adjustment while maintaining consistent valve operation. This design combines traditional Harley-Davidson® engine architecture with modern mechanical refinement. The overall configuration is engineered to support reliable operation during extended riding conditions.
Fuel Delivery, Intake, and Exhaust
Fuel delivery is managed through Electronic Sequential Port Fuel Injection (ESPFI), which electronically meters fuel to the engine. This system supports consistent fuel distribution and throttle response throughout the operating range. Air enters through a washable synthetic felt air cleaner that provides a serviceable filtration solution. Exhaust gases are routed through a 2-1-2 dual exhaust system designed specifically for this model. Engine lubrication is handled by a pressurized dry-sump system, separating oil storage from the crankcase and supporting consistent lubrication performance.
Drivetrain and Transmission
The drivetrain configuration of the 2026 Harley-Davidson® Street Glide® 3 Limited is designed to transfer engine output efficiently while supporting touring functionality. A chain-driven primary drive uses a 34/46 ratio, while a belt-driven final drive utilizes a 30/70 ratio. Together, these components form the connection between the engine and the driven wheels. The drivetrain layout is engineered to support the motorcycle's weight, touring capacity, and performance characteristics.
Six-Speed Cruise Drive® Transmission
Power is routed through a 6-Speed Cruise Drive® transmission equipped with reverse functionality. The transmission offers six forward gear ratios, allowing riders to match engine speed to operating conditions. Overall gear ratios are listed as 10.534 in first gear, 7.302 in second gear, 5.423 in third gear, 4.392 in fourth gear, 3.742 in fifth gear, and 3.000 in sixth gear. This progression provides a structured reduction through the gear range while maintaining highway-oriented capability in higher gears. The transmission serves as a key component in the touring-focused design of the 2026 Harley-Davidson® Street Glide® 3 Limited.
Clutch and Reverse System
The clutch utilizes a mechanically actuated 10-plate wet design with Assist and Slip functionality. This configuration supports controlled engagement and operation while integrating assist and slip characteristics within the clutch assembly. The 2026 Harley-Davidson® Street Glide® 3 Limited also features an electric reverse system actuated through handlebar-mounted controls. This dedicated reverse function provides additional maneuverability during parking and low-speed positioning. The integration of reverse operation reflects the practical touring focus of the three-wheel platform.
Chassis Design and Dimensions
The chassis of the 2026 Harley-Davidson® Street Glide® 3 Limited is built around a mild steel frame featuring a square-section backbone with twin downtubes. This structure forms the foundation of the motorcycle while supporting the engine, suspension, and body components. The swingarm is constructed from permanent mold cast aluminum, contributing to the overall chassis design. Steering geometry includes a 26-degree rake, a 32-degree fork angle, and 3.8 inches of trail. Combined with a 67.7-inch wheelbase, these measurements define the motorcycle's physical layout and steering characteristics.
Overall Size and Seating
The 2026 Harley-Davidson® Street Glide® 3 Limited measures 105.7 inches in overall length, 57.3 inches in overall width, and 56.5 inches in overall height. Laden seat height is listed at 27.3 inches, while unladen seat height measures 28.9 inches. These dimensions contribute to the motorcycle's touring-oriented configuration and rider accommodation. Static ground clearance measures 5.1 inches, providing defined separation between the motorcycle and the riding surface. Together, these measurements establish the model's physical footprint and rider positioning characteristics.
Weight Ratings and Carrying Capacity
The motorcycle has an as-shipped weight of 1,213 pounds and a running-order weight of 1,250 pounds. The Gross Vehicle Weight Rating is listed at 1,700 pounds. Gross axle weight ratings are specified at 511 pounds for the front and 1,189 pounds for the rear. These ratings define the vehicle's load-carrying parameters within the manufacturer's specifications. The 2026 Harley-Davidson® Street Glide® 3 Limited also provides 7.1 cubic feet of luggage volume, supporting extended touring use and storage requirements.
Suspension, Wheels, and Tires
The suspension system of the 2026 Harley-Davidson® Street Glide® 3 Limited is designed to support rider comfort and chassis control across a variety of road conditions. Both the front and rear suspension systems are matched to the motorcycle's touring mission and overall vehicle weight. The combination of suspension travel and adjustable components contributes to ride quality and handling characteristics. These systems work alongside the wheel and tire package to support stability and control.
Front and Rear Suspension
Front suspension duties are handled by a 49 mm dual bending valve fork. This assembly provides 4.6 inches of front wheel travel, allowing the suspension to absorb road irregularities and maintain tire contact. At the rear, the motorcycle utilizes hand-adjustable emulsion rear suspension components. Rear suspension travel measures 3.5 inches. The adjustability of the rear suspension allows riders to accommodate varying load conditions while maintaining consistent ride characteristics.
Wheel and Tire Configuration
The 2026 Harley-Davidson® Street Glide® 3 Limited rides on gloss black and machined 10-spoke cast aluminum wheels. The front wheel measures 19 inches in diameter and 3.5 inches in width, while the rear wheels measure 18 inches in diameter and 7 inches in width. Tire equipment includes a Dunlop® Harley-Davidson® Series bias blackwall front tire and radial blackwall rear tires. The front tire specification is 130/60B19 M/C 61H, while the rear tire specification is P215/45R18 83T. This wheel and tire package forms an integral part of the motorcycle's chassis and handling system.
Braking Systems and Rider Safety
The braking system of the 2026 Harley-Davidson® Street Glide® 3 Limited combines substantial hardware with electronically managed rider assistance technologies. The braking package is designed to provide controlled stopping performance while integrating multiple safety-oriented systems. Mechanical brake components and electronic features work together to support rider confidence and operational control. This combination reflects the motorcycle's emphasis on touring capability and rider support.
Brake Hardware
The front braking system utilizes dual floating rotors paired with 32 mm four-piston fixed calipers. Rear braking is managed through a fixed rotor and a floating 36 mm piston caliper with an integrated parking brake. Front and rear rotor diameters both measure 11.8 inches. Front rotor thickness is specified at 0.197 inches, while rear rotor thickness measures 0.276 inches. The front braking system utilizes dual rotors as standard equipment, contributing to the overall braking package.
Rider Safety Enhancements
The 2026 Harley-Davidson® Street Glide® 3 Limited includes Anti-lock Brake System functionality as standard equipment. Electronic Linked Braking is also included, providing coordinated brake operation through the electronic braking system. Traction Control System functionality is integrated into the motorcycle's rider assistance package. Drag-torque Slip Control System technology is included as well, adding another layer of electronic intervention capability. Tire Pressure Monitoring System equipment provides tire-pressure information as part of the motorcycle's overall safety package.
Cornering-Enhanced Technologies
The motorcycle incorporates several cornering-enhanced safety systems. Cornering Enhanced Anti-lock Brake System is included to expand braking functionality during cornering situations. Cornering Enhanced Electronic Linked Braking is also included in the braking package. Cornering Enhanced Traction Control System supports traction management while the motorcycle is turning. Cornering Drag-Torque Slip Control System further extends the motorcycle's electronically managed safety technologies. Together, these systems form a comprehensive suite of rider assistance features.
Electrical Systems and Rider Technology
The electrical system of the 2026 Harley-Davidson® Street Glide® 3 Limited supports starting, charging, lighting, rider information, navigation, and accessory operation. The motorcycle uses a sealed, maintenance-free 12-volt battery rated at 28 amp-hours and 405 cold cranking amps. Charging is provided through a three-phase 48-amp system capable of producing 600 watts at 13 volts and 2,000 rpm, with maximum output listed at 625 watts. Starting is handled by a 1.6 kW electric starter featuring solenoid shift starter motor engagement. These components form the foundation of the motorcycle's electrical architecture.
Lighting and Vehicle Information
LED lighting is utilized throughout the motorcycle, including the headlamp, tail and stop lamp, front signal lights, and rear turn signals. LED fog lamps are integrated into the lower fairings, expanding visibility-related equipment. Digital gauges are integrated directly into the display system, allowing vehicle information to be presented within the central screen interface. The vehicle information screen includes air temperature, oil pressure, and EITMS information. This arrangement centralizes rider information while maintaining a modern display environment.
Navigation and Accessory Power
The 2026 Harley-Davidson® Street Glide® 3 Limited includes an embedded navigation system that provides traffic and weather information through a Wi-Fi hotspot connection. The navigation system is integrated directly into the motorcycle's technology package. A 15-watt USB-C accessory power outlet is located in the media storage box. This connection supports compatible electronic devices and accessory charging requirements. These features contribute to the motorcycle's touring-oriented functionality and connectivity.
Infotainment and Connectivity
The infotainment system serves as a major technology feature of the 2026 Harley-Davidson® Street Glide® 3 Limited. The motorcycle utilizes Skyline™ OS operating software and a 12.3-inch full-color TFT display. This screen functions as the primary interface for audio, vehicle information, communication, and navigation features. The system integrates multiple connectivity options while maintaining a centralized control environment. Its configuration supports both rider information and entertainment functions.
Audio and Communication Features
Audio output is rated at 50 watts per channel and is delivered through four speakers. The speaker configuration includes two 6.5-inch fairing speakers and two 6.5-inch Tour-Pak® speakers. AM and FM radio functionality are included as standard equipment. The system also supports SD card, flash drive, and MP3 playback through USB connectivity. Hands-free mobile phone operation is available through Bluetooth® integration, expanding communication capabilities during travel.
Smartphone Integration
Apple CarPlay® compatibility is available through both wired and wireless connections. Bluetooth® supports phone, media player, and headset connectivity functions. USB-C, MTP, and smartphone connections are supported through the connection point located within the inner fairing storage compartment when compatible adapters are used. Rider and passenger intercom functionality is supported through compatible headset equipment. These connectivity features help integrate mobile devices and communication tools into the motorcycle's infotainment system.
